Copper Beryllium Precision Wire

EN: CuBe2

UNS: C17200

Standards: YS/T 1714-2024

jinjiang@kinkou.cn

Tel: 008613773014250

Whatsapp: 8613773014250

Copper Beryllium Precision Wire
description1
Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Description

Quick Detail:
C17200 alloy is premium, non-ferrous alloy products renowned for their exceptional combination of properties, making them indispensable in high-performance engineering applications.
Wire size from Dia.0.02mm to Dia.0.5mm



Key Characteristics & Advantages:

High Elasticity: Superior to phosphor bronze/silicon bronze by 3–5×, ideal for springs and contacts.

Wear & Corrosion Resistance:Low surface wear rate in abrasive tests. Resists saltwater, acids, and PVC degradation.

Thermal Stability: Maintains conductivity from -50°C to 200°C.

Precision Formability: Wire diameters: 0.01mm~0.60mm. Supplied pre-hardened (no post-forming heat treatment needed)



Chemical composition (wt,%)：
Be Ni+Co Ni+Co+Fe Al Si Cu
1.8~2.0 ≥0.2 ≤0.6 ＜0.2 ＜0.2 Rem.



Core Applications:

C17200 wire is critical in precision components requiring strength + conductivity:
Electronics: Battery contact springs, micro~motor brushes, relay contacts.

Aerospace: Bearings, navigation instruments, engine components.

Automotive: Spark plugs, ignition switches, sensors.

Industrial: Oil drilling tools, anti-sparking tools, shielding materials.



Physical and Mechanical property：
Temper Size Tensile Strength（Rm) Elongation Eletric Conductivity
mm MPa min.%, (At200) min.%, IACS
TB00
Solid Solution Treatment		 0.01~0.60 390~570 10 17
TD01
Solid Solution Treatment & Cold Process Hardning		 620~805 5
TD02
Solid Solution Treatment & Cold Process Hardning		 760~930 3
TD03
Solid Solution Treatment & Cold Process Hardning		 0.01~0.05 835~1050 0.9
＞0.05~0.20 784~1078 1
＞0.20~0.60 686~980 1.3
TD04
Solid Solution Treatment & Cold Process Hardning		 0.01~0.60 1100~1450 1.1
TH03
Precipitation Hardening		 0.01~0.25 1310~1585 0.9 23



Size Average grain size（mm）
0.01~0.05 0.0003~0.017
＞0.05~0.10 0.017~0.02
＞0.10~0.60 0.02~0.12



Core Application:

Electronics Connectors, relay springs, micro-motor brushes, shielding
